CSA B167:26 Is Current — But Which Edition Actually Applies at Your Canadian Site?

CSA B167:26 is the current national standard for overhead travelling cranes, gantry cranes, monorails, hoists and trolleys as of the date of writing. A reasonable conclusion is that every Canadian crane program should now be written to it.

That conclusion is incomplete, and on some sites it is wrong.

Current is not the same as incorporated

Canadian overhead crane requirements vary by jurisdiction, equipment type and workplace. Provincial regulations may incorporate specific editions of CSA B167 or other standards, while owner and site requirements can be more stringent.

Alberta's OHS Code Part 6, for example, references CAN/CSA B167-96 (R2007) for maintenance and inspection at Section 94 — an edition three decades older than the current one, and one CSA has withdrawn. British Columbia's OHS Regulation section 14.2(3)(a) names CSA B167-96 as well, with ASME B30.2, B30.11, B30.16 and B30.17 offered as alternatives. Saskatchewan is two generations ahead of both: its approved-standards listing for Part 13 names CSA B167-16 (R2021). Ontario Regulation 854, which governs mines and mining plants, uses CSA B167-16 (R2021) duty-classification language.

A western Canadian owner therefore runs cranes under two different editions in the same fleet. For the technical differences between them — including what B167-96 does not cover at all — see the three-edition comparison of B167-96, B167-16 and B167:26.

None of that makes B167:26 irrelevant. It means the edition an inspector can enforce and the edition representing current practice may be different documents, and the owner is responsible for knowing which is which.

Four layers, not one

• The current national standard. What the industry treats as current good practice.
• The edition incorporated by regulation. What is enforceable in that jurisdiction.
• Owner and site standards. Frequently more stringent than either, and enforced through contract and site access.
• Manufacturer instructions and engineering requirements. Apply in their own right, and modifications or re-rates can trigger professional engineering involvement regardless of the other three.

All four can apply simultaneously. Where they conflict, the more stringent requirement generally governs in practice — but that is a judgement made with the site's specific facts, not a rule to apply blindly.

Why owners get caught

The common failure is a corporate program written once, against one reference, and rolled out to every site. It holds up where the reference happens to match, and quietly does not where it does not. The gap usually surfaces at the worst moment: an audit, an insurance renewal, or after an incident.

The second failure is the opposite — updating everything to the newest edition and assuming that closes the question. It does not address whether the site's own standards go further, or whether the records demonstrate what the regulation actually requires.

What to do instead

Establish the applicable requirements before you write or revise the program: the jurisdiction, the workplace type, the equipment, the incorporated edition, the owner standard and the manufacturer requirements. Then test whether the evidence you hold can demonstrate them.

That establishment step is the part most programs skip, and it is where an independent review earns its cost.

Next step: Request a Crane Safety & Compliance Review, or read the Canadian overhead crane safety overview.
